Fridge Slide | Off-Grid Modular Drawer System
No reviews yet. Write review.
$425.00
Code: OGFRS
Weight: 45 (lbs)
Free Shipping!
- Single-handed operation.
- Mounting hardware & drawer slides included.
- Two mounting configurations; low and top-mount.
- Low configuration will fit up to a CFX3 55qt fridge.
- Interior dimensions (low mount): 30"x18.75".
- Exterior dimensions: 31.5"x21.25"x3.875"
- Top-mount is not limited by the drawer size and will fit larger fridges.
- Tie-down points at the front and rear.
- Cut and formed from .075" steel.
- Sold individually.
- Proudly designed and made in the USA.
Organize your gear safely and efficiently! Fridge slide designed to mount to the Victory 4x4 Off-Grid Floor System. Drawer and latch coated with a 2 stage satin textured black powdercoat over durable zinc primer finish. Drawer face coated with a silver textured powdercoat over durable zinc primer finish.
Although the Off-Grid Drawers and Fridge slides are rated for 250 lbs individually, load your system with your own descresion, and avoid putting heavier items in upper cabinets.
Looking for answers to common questions about us or our products? See our FAQ here.
7 Questions asked on Fridge Slide | Off-Grid Modular Drawer System
•
Ask us anything
Q
Walter • 04/23/2023, 7:49:26 PM
2021 4Runner here. Can I just purchase and install the fridge slide or do I also need to purchase and install the other cargo area base first?
A
04/27/2023, 10:29:28 AM
You will need our Floor plate or another floor that can be modified to bolt the slide to.
Q
Walter • 04/24/2023, 9:22:54 AM
What are the exact dimensions of the inside of the fridge slide? Be great to know exact and all dimensions of the fridge slide. Appreciate y'all and great product!
A
04/27/2023, 10:34:16 AM
Interior dimensions (low mount): 30"x18.75".
If you flip the slide to have the flat side up (top mount), you can mount a fridge larger than the slide as well.
Q
Chris Baltazar • 06/01/2023, 8:38:36 AM
Can you mount this on top of one of the offgrid modular drawer system?
A
06/22/2023, 10:36:02 AM
This designed to mount to our floor system, it would not mount on top of the drawers themselves.
Q
Rob • 07/02/2023, 7:27:00 PM
What is the weight capacity of the drawer slide?
A
08/04/2023, 4:28:24 PM
We do not have an official weight rating.
Q
Daniel • 09/26/2023, 2:04:01 PM
What is the height/depth of the drawer? Ie 2”, 3”, etc? Does it level when the rear seats are down? I sleep in the Runner and need to be sure it will be level.
A
12/07/2023, 10:54:12 AM
The overall height from the floor would be roughly 4".
Q
Ingvar Corona • 01/18/2024, 9:12:31 PM
What is the largest Dometic and Iceco fridge models it can fit/support?
A
01/19/2024, 10:17:33 AM
The low configuration will fit up to a CFX3 55qt fridge.
Q
MRAD • 07/01/2024, 12:11:07 PM
The listed dimensions show the same interior and exterior lengths, but that can't be true. Will you please provide the actual exterior and interior dimensions?
A
07/02/2024, 4:51:15 PM
The listed dimensions have been updated. The exterior length is 31.5" to the outside of the "press" bracket.
There are no reviews for this item yet.
Write a Product Review: Fridge Slide | Off-Grid Modular Drawer System
Please note: Install videos are meant to be used as a guide, and aren't always the most up to date information on product installation and improvements.
Please be sure to read the PDF installation instructions as well.
